Function |
BIN-8 Direct Drive Mult-functions |
BIN-9 Direct Drive Mult-functions |
Motor Type |
Direct Drive Motor |
Direct Drive Motor |
Voltage Range |
165-250V |
165-250V |
Output Power |
350W |
400W |
Current |
4.5A |
4.5A |
Frequency |
50Hz |
50Hz |
Cartons |
2 |
2 |
Poles |
8 |
8 |
Revolutions |
0-600r/min |
0-3500r/min |
Torques |
0.20mm |
0.20mm |
Needle Position |
Upper Position |
Upper Position |
E-01 Hardware Short-Circuit Protection |
Damaged Controller Driver,Motor Coil Short Circutit,Instantaneous Over Current
|
E-02Software Over-Crrent Protection |
Over Load |
E-03Overload Protection |
Beyond The Motor Power |
E-05 Inut Voltage Protection |
Power Supply Voltage Beyond The Scope |
E-06 Stall Protection |
Locked-rotor Or Motor Phase Missing |
E-07 No-load Protection |
Rising Sensor Failure,Magnet/Sensor/Wiring/Motor Missed |
E-013 Encoder Fault |
Poor Contact Or Damage To The Motor Encoder |
E-15 Pedal Fault |
Pedal Plug Connection Is Bad Or Circuit Problems |
